Measures the distance from a line to a selected point. Perfect for blade edge damage, gap width, and weld width. The perpendicular measurement method ensures consistent results even when working on angled or irregular surfaces.

Example Use Cases

• Width of a discontinuity along a blade edge
• Dimensional span of a gap, groove, or weld profile

Measures the distance from a reference plane to a selected point. Whether assessing corrosion, dents, or weld height, depth measurement provides a clear understanding of how far a feature extends above or below a reference surface.

Example Use Cases

• Depth of an isolated corrosion or erosion pit
• Extent of FOD impact damage on a component surface
• Height deviation of a weld crown or wear groove

Calculates the total length along an irregular path. By placing multiple cursors along the feature of interest, this tool measures the true geometry of any discontinuity that changes direction.

Example Use Cases

• Total length of irregular surface
• Total length of a jagged crack

Measures the planar surface area of a feature by outlining its boundary with multiple cursor points. Area measurement provides a quantifiable, two-dimensional representation of the surface area damage or material area loss.

Example Use Cases

• Extent of coating loss on a component surface
• Total surface area of a corrosion or pitting field

Generates a cross-sectional map of surface variation, identifying the highest and lowest points relative to a reference plane. Ideal for visualizing and quantifying subtle or complex surface geometry.

Example Use Cases

• Cross-sectional profile of a corrosion or erosion pit
• Surface deviation along a weld or wear groove

Measures the three-dimensional angle between two lines defined by three user-placed points on a surface. Ideal for assessing angular relationships on flat or complex geometry.

Example Use Cases

• Erosion angle of a wear surface on a turbine blade or vane platform
• Angular measurement of material loss on an oil and gas chute or valve seat

Measures the three-dimensional angle between two user-defined planes, each determined by three cursor points. Ideal for quantifying the angular relationship between two adjoining surfaces.

Example Use Cases

• Bend angle of a deformed or impacted structural component
